Usually the base that is bolted into a large concrete pad provides the essential support for a tower crane. The base is connected to a mast or a tower and stabilizes the crane which is affixed to the inside of the structure of the building. Usually, this attachment point is to a concrete lift or to an elevator shaft.
Typically, the mast is a triangulated lattice structure measuring 10 feet square or 0.9m2. The slewing unit is attached to the very top of the mast. The slewing unit consists of a gear and a motor which allows the crane to rotate.
Tower cranes may have a max unsupported height of 80m or 265 feet, while the minimum lifting capacity of a tower crane is 16,642 kg or 39,690 lbs. with counter weights of 20 tons. Additionally, two limit switches are utilized to be able to make certain that the operator does not overload the crane. There is even one more safety feature referred to as a load moment switch to ensure that the operator does not exceed the ton meter load rating. Finally, the maximum reach of a tower crane is 230 feet or 70 meters.
There is certainly a science involved with erecting a tower crane, specially due to their extreme heights. At first, the stationary structure needs to be transported to the construction location by using a big tractor-trailer rig setup. Then, a mobile crane is used in order to assemble the machinery part of the jib and the crane. These parts are then attached to the mast. The mobile crane then adds counterweights. Crawler cranes and forklifts could be a few of the other industrial machines which is typically used to erect a crane.
When the building is erected, mast extensions are added to the crane. This is how the crane's height is able to match the building's height. The crane crew utilizes what is referred to as a top climber or a climbing frame which fits between the top of the mast and the slewing unit. A weight is hung on the jib by the work crew so as to balance the counterweight. Once complete, the slewing unit can detach from the top of the mast. In the top climber, hydraulic rams are used to adjust the slewing unit up an additional 20 feet or 6.1m. Then, the crane driver uses the crane to insert and bolt into place another mast part piece.
